Maxlite 15 Watt, 5000K, 120-277 Volt LED Small Wallpack with Photocell and Battery Backup

SKU: 103275 | Ordering Code: SECR12U-50BPCEM0 | UPC: 767627255601

Printer friendly

$179.49each

Add to Cart

Save to BulbTrack

Quickly and easily order the products you have purchased in the past or plan to order in the future by simply adding them to your My BulbTrack page.

Once a product has been added to My BulbTrack, ordering it is as easy as entering the quantity or clicking on the product image. You can even add notes to each product to record where it is used in your business or home.

In StockReady to ship

This item does not ship outside the US

This item qualifies for free ground shipping *

Product Highlights

Energy efficient replacement for a conventional 75 watt bulb
Estimated life of 22.8 years based on 3 hours use per day

Description

Lighting Facts Per Bulb

Brightness 1286 lumens

Estimated Yearly Energy Cost $1.81

Based on 3 hrs/day, 11¢/kWh

Cost depends on rates and use

Life

Based on 3 hrs/day22.8 years

Light Appearance

WarmCool

5000 K

Energy Used15 watts

Maxlite 15 watt, 5000K, 120-277 volt LED small wallpack fixture is ideal for security, pathway, perimeter or entryway lighting. Slim, low-profile wall pack with architectural contemporary design. Well engineered and high quality die-cast aluminum which delivers high bright crisp light. Excellent heat dissipation will ensure its performance over the life.

NiCad battery backup provides up to 90 minutes of emergency light
Self diagnostic function included with test indicator light
4.8V maintenance free NiCad battery
1/2" threaded conduit at the top for surface conduit applications
Durable die-cast aluminum housing with corrosion resistant powder coat finish
UV stabilized polycarbonate lens
1,286 lumens in AC mode, 350 lumens in battery mode
Field-selectable wiring allows AC operation to be controlled using either a wall switch, photocell or other switching mechanism
120V-277V photocell included
Meets UL924 & WL
NFPA 101 Life Safety Code, NEC, OSHA and CEC Compliant

Product Documents

Manufacturer Spec Sheet

Full Specs

Brand	MaxLite
Product Line	Guardmax
Model Number	SECR12U-50BPCEM0
Energy Used A rating, expressed in watts, to indicate the rate at which a lamp consumes energy. Also known as wattage value.	15 Watts
Incandescent/Halogen Equivalent The wattage value of an incandescent or halogen lamp of similar brightness.	75 Watts
Line Voltage	120-277
CRI Color Rendering Index is an international system used to rate a lamp's ability to render object colors. The higher the CRI (based upon a 0-100 scale) the richer and more accurately colors generally appear. CRI differences among lamps are not usually visible to the eye unless the difference is more than 3-5 points.	70
Color Temperature (Kelvin) An expression of the hue of the light emitted, measured in degrees Kelvin. Usually expressed by a four digit number followed by (k), such as 2700k. Higher temperatures indicate whiter, "cooler" colors, while lower temperatures indicate yellower, "warmer" colors. Some common Kelvin temperature benchmarks are 2700k (warm white), 3500k (neutral white), 4100k (cool white), 5000k (bright white), and 6500k (daylight).	5000
Brightness (Lumens) A rating of the initial light output of a bulb, rated after 100 hrs of operation. Lumens are a measure of how much light falls on one square foot of area, one foot away from the light source.	1286
Average Rated Life (hr) A measurement of the average length of time, between first use and the point when 50% of the lamps tested have stopped functioning, , using an operating cycle of 3 hours on, 20 minutes off.	25000
Operating Temperature (°F) The ambient temperature in which the product can safely operate.	32 to 122

Bulb Type Supplied Type of bulb supplied with the fixture	LED
Width (in) For fixtures and ballasts, width is the measurement of the total horizontal distance from left to right of the product in inches.	6.6
Height (in) For ballasts and fixtures, height is the measurement of total vertical distance from the top of the product to the bottom expressed in inches.	10.5
Depth (in) For fixtures and ballasts, depth is the measurement of total distance from front to back of the product in inches.	3.6
Finish The decorative finish of the item.	Bronze
Housing	Aluminum
Mounting	J-Box
Warranty	5 year limited
Photocell	Yes
Wet Location Suitable for exterior or interior location in which uncontrolled liquid may drip, splash or flow on or against electrical equipment.	Yes
Battery Backup Has a backup battery to allow it to continue functioning in case of power failure.	Yes
